Numbered Residential Garage Door Hinge
Numbered #1 through #5 sectional door hinges in wide-body 3" and narrow-body 2¼" configurations and 14, 13, 11, 16, and 18 gauge variants. Hot-rolled galvanized steel construction, graduated to match panel position and track angle per ANSI/DASMA 102 and 116. Every production lot is inspected for hole-pattern alignment and galvanization coverage before it leaves our vetted manufacturing partner.
Also known as
garage door hinge · panel hinge · sectional hinge · #1 hinge · #5 hinge
Key Features
- Graduated to panel/track angle per DASMA convention
- Galvanization coverage verified per production lot
- Hole-pattern alignment inspected before release
- Matched to standard 14-ga residential door sections
Available Materials
Specifications
